Digital Alliance offers a 1-year limited warranty on this products.
The Limited Warranty Period starts from the date of purchase. If there is any issue, please contact us via support@da.co.id
SPECIFICATION |
|
|---|---|
AC INPUT |
|
| Model | PBZ 750W 80+ Bronze |
| Form Factor | ATX |
| Dimensions | 160(L) x 150(W) x 86(H)mm |
| Voltage Range | 200 – 240V AC |
| Current | 6A |
| Frequency | 50 – 60Hz |
| Color | White |
| 80 PLUS Certification | Bronze |
DC OUTPUT |
|
| Red | +5V (10A) |
| Orange | +3.3V (10A) |
| Yellow | +12V (54A) / +12V2 (14A) / +12V3 (14A) / +12V4 (14A) |
| Blue | -12V (0.3A) |
| Purple | +5Vsb (2.5A) |
POWER CONNECTOR |
|
| Main Power (24 pin) | 1 |
| ATX 12V (4+4 pin) | 1 |
| PCI-E (6+2 pin) | 1 |
| Sata (4 pin) | 1 |
